Parameter |
Specification |
|
Manufacturer |
CHINT Electrics |
|
Series / Model |
NXB-63H (High breaking capacity series) |
|
Number of Poles |
1P |
|
Tripping Characteristic |
Type C |
|
Rated Current |
20 A |
|
Rated Frequency |
50 / 60 Hz AC |
|
Rated Breaking Capacity |
10 kA |
|
Rated Operational Voltage |
220 V / 230 V / 240 V AC (Single Phase) |
|
Rated Insulation Voltage |
500 V |
|
Rated Impulse Withstand |
4 kV |
|
Compliance Standard |
IEC/EN 60898-1 |
|
Terminal Capacity |
Up to 25 mm² rigid/stranded wire |
|
Tightening Torque |
2.0 N·m |
|
Mounting |
Standard 35 mm DIN rail |
|
Protection Degree |
IP20 |
|
Operating Temperature |
-35°C to +70°C |
